RCC Works:
Isolated footings in foundation, Columns, Beams and floor slabs Earthquake resistant as per structural Design & in accordance IS 1893-2002 & IS 456-2000
Block Works:Bricks/ Blocks
4’’ thick partition walls
All internal walls M.S rod as shear band @ every 4’0’ height
9’’ thick peripheral / Main wall
External walls with sill beams for window openings
Plastering Works:
RCC surfaces like ceiling underside Floor slabs, beams, sunshade Main & partition walls
Internal & External Surfaces
Anti-Termite Treatment:
Foundation & Basement. As per IS 6313-1981
Water Proofing:
Toilet Sunken, o.H.T , weathering course etc. (forcerock / BASF/ Equivalent)
Flooring Works:
2’0’*2’0’ joint free vitrified tiles for living, Bedroom Floor(Royal Touch/ Kajaria / Asian / Equivalent)
12’’*12’’ Ceramic tiles of anti-skid quality for toilet, Balcony floor(Royal Touch/ Kajaria / Asian / Griffine/ oreavaa/Equivalent)
8’’*12’’ -2’0’’ height wall dadoing ( Kajaria / Asian / Griffine/Somany/Equivalent)
2’0’’ wide granite kitchen platform (Black Color Granite polished with single nosing)
Kitchen SS Sink(Single Bowl) (Prince/ Diamond/ Equivalent)
Doors:
Teak wood – Main door frame
Sal Wood – Other Inner doors frame
Main Door Shutters – Teak wood with godrejlock & fittings
Other Door Shutters – Flush door shutter with necessary lock and fittings
Window:
UPVC windows catchment type with / without Grill provision as per architect Design
Steel Works:
MS Grills for windows – MS Square / Flat rods well painted with Enamel
Lift:
Automatic openings, 5+1 Capacity – Johnson / Kone / Equivalent
Electrical Works:
EB mains 3 phase supply circuit wiring with insulated copper conductors in PVC conduits and with earthing for each circuit and Earth pits grounded (Finolex / Anchor / Orbit / Kundan / Equivalent)
Modular switches (Anchor Roma / Havells / Equivalent)
Painting Works:
Ceiling with 1 coat primer + 2 coats O.B.D (Asian/ Berger/ Jordon / Equivalent)
Inner wall surfaces with putty and 1 coat primer + 2 coats interior emulsion(Asian/ Berger/ Jordon / Equivalent)
External surfaces with 1 coat primer + 2 coats Exterior Emulsion Paint(Asian/ Berger/ Jordon / Equivalent)
Main door varnish polish(Sheenlac)
All other doors and MS grills works with 1 coat primer +2 coats synthetic enamel paint (Asian/ Berger/ Equivalent)
Plumbing Works:
Water supply lines with graded sections of CPVC pipes for hot & cold water lines and PVC pipes for other lines(Ashirvad / Supreme / Astral/ Equivalent)
Waste water lines with PVC pipe lines with inspection chambers and PVC pipes for other lines(Supreme / Finolex / Varun / Equivalent)
Viteous sanitary fitting white in color wash basin in toilets & dinning IWC/EWC in toilets (Kohler/ hindware / RAK / Equivalent C.P fitting (metro/kohler/jaquar/equivalent)
Site Improvement:
Compound wall – designed by the architect with lighting main gate & arch – designed by the architect with lighting
Rain water harvesting – designed by the architect as per the requirement stilt floor – CC flooring in covered parking, staircases & corridors floors (Kota/ thandoor stone flooring)
Pavemnts / Roads – interlocking concrete pavers / BT bore well – as per the requirement sump – RCC – designed by the architect ass per the required capacity over heads tank – RCC – Designed by the architect as per the required capacity
