KPN Grand in Urapakkam

Foundations & Structure :

Framed Structure (RCC - Columns, Plinth / Tie Beams, Sunshade & Roof Slabs) Mild steel Floor to floor height of 10 feet.

Wall :

9” thick load bearing brick work all external walls and 4.1/2” thick brick work for all inside partition walls.

Basement :

3 Feet height from existing ground level filled with pit sand well consolidated and PCC with 40mm jelly to receive flooring, RCC plinth beam at floor level along the load bearing walls will be provided.

Plastering :

Ceiling plastering 12mm thick in cement & sand 1:3 and wall plastering using cement & sand 1:4 for all inside and 1:5 for outside walls

Joineries :

Main door will be of Teak Wood, other rooms flush doors, Toilet Doors will be of PVC, Windows will be of UPVC.

Grills :

All windows will be fitted with MS Grills

Lofts:

In shorter span one side in Bedrooms and two side in kitchen

Kitchen:

Platform finished with Granite slab and the wall above platform dadoes with glaze tiles up to a height of 4 feet and SS sink with necessary Tap Connections.

Painting:

Ceiling –Two coat of white colour.

Inner wall

Rolex Patti one Coat and one Coat Primer

Two Coats Emulsion Paint,

Outer wall

One Coat white Cement and Two Coats of paint.

All doors, Windows & Grills will be painted with one coat of primer and 2 coats of Enamel.

Electrical:

Concealed Electrical lines using PVC pipes, 7/20 Wires (ISI, FR) for main lines, 3/20 for power points and 1/18 wire for all other points. Livon makes switchers and sockets will be provided

3 Phase Supply

Inverter Wiring.

AC point in all Bedroom

Geyser point in Both toilet

Bore well :

Minimum 100 feet bore well depth

Best motor company will be provided

Kaveri tank is provided with the capacity of 750 litres.

Flooring:

Tiling for the floorings of all rooms will be size 2 feet x 2 feet Vitrified Nano Tiles

Tiles cost @ Rs. 50 per Sq.ft.

Plumbing:

Plumping fittings and shall be chrome plated with brass internals. Pipe shall be concealed by plumping. Hand shower Cum Head shower shall be provided. Washing machine connection.

Two toilet will be provided with hot and cold water connections

Using PVC pipes for Hot & Cold water lines.

Sanitary (Hindustan)

All sanitary ware will be in white colour IWC. One wash basin will be provided.

Bath Tilling:

All Toilet wall will be in plain colour glazed tiles up to a height of 7 feet and flooring also will be a plain ceramic tiles. Tiles Cost @ Rs.30 per Sq.Ft. ?R.C.C Sump and OHT - Rs.22 per litres.

Compound wall Rs.1400 / R.ft and Height 5 feet.

Elevation Work

Wooden Doors for Cupboards & Lofts

Granite and Marble Flooring

M.S Safety Grill Gate

Weathering Course and Weathering Tile in Terrace.

SS Handrail.

Soak Bit.
