STRUCTURE
Structural System : RCC Framed structure designed for seismic compliant (Zone - 3).
Masonry : 200mm for external walls & 100mm for internal walls.
Floor- Floor height (incl. slab) : Will be maintained at 2950mm.
WALL FINISH
Internal walls : Finished with 2 coats of putty, 1 coat of primer & 2 coats of Premium emulsion.
Ceiling : Finished with 2 coats of putty, 1 coat of primer & 2 coats of Premium emulsion.
Exterior walls : Finished with 1 coat of primer & 2 coats of exterior Emulsion paint with color as per architect design.
Bathroom : Glazed / Matte ceramic tiles of size 600mm x 1200mm for height of 2450mm and will be finished with a coat of primer above false ceiling.
Toilet ceiling : Grid & Panel type false ceiling.
FLOOR FINISH WITH SKIRTING
Foyer, Living, Dining & Internal Passage : Marble Flooring.
Kitchen & Bedrooms : Vitrified tiles of size 1200mm x 600mm.
Bathroom : Anti-skid ceramic tiles of size 600mm x 600mm.
Balcony : Wooden finish tile flooring of size 600mm x 1200mm.
Private open terrace (If Applicable) : Wooden finish tile flooring of size 600mm x 1200mm.
KITCHEN & DINING
Electrical Point : For Chimney and Water Purifier
Dining : Granite Counter mounted washbasin and wall dado of height 200mm.
Kitchen : Will be left open for modular work with Electrical points and plumbing provisions.
BALCONY
Handrail : MS handrail as per architect’s design intent. Sill coping with granite.
Cloth Drying Hanger : Ceiling mount cloth drying hanger provided in living balcony.
BATHROOMS
CP & Sanitary fixtures : TOTO or equivalent.
Master Bathroom : Wall mounted WC with cistern, flush plate and health faucet, single lever diverter, spout, Rain shower, hand shower, glass partition for shower, granite counter mounted wash basin and 2’ long trench drain.
Other Bathrooms : Wall mounted WC with cistern, flush plate and health faucet, single lever diverter, Overhead shower, spout, granite counter mounted wash basin and square designer drain.
JOINERY
Main door : Veneer finish full jamb architrave with double side Veneer finish door of size 1200x2300mm.
Ironmongeries like Digital lock system of Yale or equivalent lock, tower bolt, door viewer and magnetic catcher.
Bedroom doors : Laminate finish full jamb architrave with double-sided laminate finish door of size 900 x 2300mm. Ironmongeries like Yale or equivalent lock, Designer door, tower bolt, Door Brush, etc.,
Bathroom doors : Good quality door frame with double-sided laminate finish door of size 750 x 2300mm. Ironmongeries like thumb turn of lock of Yale or equivalent without key, Door bush, tower bolt, etc.,
WINDOWS
Windows : Powder coated Aluminum windows with sliding shutter with see through Toughened glass and MS grill / Railing on the inner side. Sill coping with granite.
French doors : Powder coated Aluminum frame and doors with toughened glass.
Ventilators : Powder coated Aluminum frame of fixed Glass / open-able shutter for ODU access (wherever applicable). Sill and Soffit coping with granite.
ELECTRICAL POINTS
Power Supply : 3 PHASE power supply connection.
Safety device : MCB & RCCB (Residential Current Circuit breaker).
Switches & sockets : Modular box, switches & sockets of Schneider or equivalent will be provided.
Wires : Fire Retardant Low Smoke (FRLS) copper wire of a quality BIS brand.
5 AMP socket (outdoor) : Point provided in the balcony in recommended location.
Foot lamp : Provided in all bedrooms.
Fan point : Point Provided in kitchen.
TV : Point in Living & any one bedroom and provision in other bedrooms.
Data : Point in Living & any one bedroom.
Split- air conditioner : Points will be given in living / Dining and in all bedrooms.
Exhaust Fan : Point in all bathrooms.
Geyser : Geyser points will be provided in all bathrooms.
Back-up : 1BHK-350W, 2BHK-400W, 3BHK-500W.
