The Summit

STRUCTURE

RCC framed structure with RC foundations conforming to Bureau of Indian Standards (BIS).

Pre constructional anti-termite treatment will be provided under the Foundation and external perimeter of the building as per BIS for the complete building.

Walls will be constructed using Autoclaved Aerated Concrete blocks (AAC blocks) – from Aerocon or equivalent. The height will be maintained at 9’10” from structural floor to floor.

WALL FINISHES

Internal walls will be finished with gypsum plaster and emulsion paint above wall putty.

The toilet walls will be finished with ceramic tiles up to ceiling height – colors and sizes will be as recommended by Architects. Trims and profiles will be used to protect the vertical edges of tiles.

Wash area will be finished with ceramic tiles up to ceiling height using tiles as recommended by our Architects.

Dado of 2’ above the kitchen platform will be finished with ceramic tiles.

Lofts will be provided in Kitchen and in one bedroom.

Exterior faces of the building including the balconies will be finished with cement plaster and weather proof paint – Ultima Protek or equivalent - texture paint will be used in all exterior faces suggested by our Architects.

CEILING

Ceiling areas of living, dining, bedrooms, kitchen, toilet and balconies will be finished with putty and emulsion paint.

TERRACE

Terrace will be chemically waterproofed and filled up with foam concrete.

FLOOR FINISHES

Living and Dining will be finished with Italian / Turkish Marble of suitable size as specified by the Architect and the Bedrooms will be finished with vitrified tiles – colors as suggested by Architects.

Kitchen, Utility, Balcony & Toilets will be finished with anti-skid ceramic tiles as recommended by Architects.

4” high skirting matching the door tile will be provided wherever required.

COMMON AREA FINISHES

Staircase & lobby door will be finished with Polished Granite / Marble slabs.

Staircase & Lobby walls will be finished with vitrified / ceramic tiles up to ceiling height.

Car parks will be finished with Granolithic dooring. Driveway will be finished with print concrete / Cement tiles - pattern will be as suggested by our Architects.

Cool Tiles in Terrace for heat reduction on foam concrete.

DOORS

Kalpataru or equivalent veneer CDS unit with Architraves on Both Sides. Shutter shall be 40mm Flush Door with Edge Banding on all 4 sides. Frames, Architrave & Shutter shall be finished with Melamine polish. Size of door is 4’-0” x 8’-0”.

Yale lock or equivalent with biometric, number pad, access card and physical key will be provided.

Kalpataru or equivalent Laminated CDS unit with Architraves on both sides. Shutters shall be 32 mm push door with both side laminate and PVC Edge Banding on all 4 sides.

Yale lock or equivalent will be provided.

Size of door is 3’-0” x 7’-0”.

Kalpataru or equivalent Laminated CDS unit with Architraves on both sides. Shutters shall be 32 mm push door with both side laminate and PVC Edge Banding on all 4 sides.

Yale lock or equivalent will be provided.

Size of door is 2’-6” x 7’-0”.

WINDOWS

UPVC/ Aluminium powder coated sliding/ fixed windows will be provided in all rooms with MS Grills as per design.

FRENCH DOORS

UPVC/ Aluminium powder coated sliding type French door will be provided.

KITCHEN

Counter top Platform (dry fixing) will be finished with 18mm thick granite slabs 2’0” wide. Stainless Steel Single bowl sink with drain board and a sink cock will be provided. Provision for fixing a refrigerator, exhaust fan (or chimney), ceiling fan, microwave, mixer and a point for RO unit for drinking water purposes will be provided.

Wash area will have Single bowl Stainless steel sink (without drain board) and provision for fixing washing machine and dish washer, will be made.

ELECTRICAL

Concealed insulated copper multi-strand FR wires will be provided with distribution board having MCBs. Necessary number of switches & sockets will be provided as recommended by our Consultant.

Telephone points/Data point will be provided in Living and Master Bedroom.

Empty conduits for DTH TV point will be provided in Living and Master Bedroom.

One charging point for E-Vehicle will be provided in the carparking area for each apartment.

LIFT

Building will be served by one number of stretcher/passenger lift with automatic openable doors – Kone or equivalent.

WASHROOMS

All Sanitary ware will be of ‘White’ Color and suitable number of CP fittings ROCA or equivalent will be provided.

Shower Partitions will be provided in all washrooms.

Overhead shower with diverter and spout will be provided in all washrooms.

All washrooms will have provision for connecting a Geyser and an Exhaust fan.

COMPOUND WALL

5’ high compound wall will be provided as specified by Architects.

POWER SUPPLY & GENERATOR

3 phase power supply with 100% generator back-up will be provided.

LANDSCAPING

The project will be suitably landscaped as per design.

SECURITY SYSTEM

CCTV, Access Control and Video intercom system will be provided.

WATER

One Bore well and water treatment plant of adequate capacity will be provided.

Underground RCC Sump of adequate capacity for Bore well / Treated water and Overhead Tank will be provided as specified by Consultant.
